iF Design Award 2021
Good Design Award 2020
Wireless Mobile 2-sided Document Scanner
- Portable with built-in rechargeable battery
- Easily scan 2-sided documents up to 15 pages per minute
- Wireless connectivity with and USB 3.0 for ease of sharing
- Built-in SD card reader for direct storage
- Easily scan A4 documents, receipts and ID cards
- Space saving "U-path" paper feed system
Information
Overview
The DSmobile DS-940DW is engineered to be truly flexible. Featuring a built-in battery, Wi-Fi and intuitive LCD panel, setup is effortless. Digitising your files whether in the office or out on the road is simple.
Enjoy scanning anywhere
Truly portable, the DSmobile DS-940DW scanner has a built-in battery, so you can enjoy scanning your documents without the need to plug into a power supply. Simply take your scanner with you, scanning where it's most convenient for you.
Stay effortlessly organised
Using Brother's free mobile app, viewing and sharing documents on your mobile phone or tablet is effortless. The intuitive LCD panel makes selecting and changing scan functions simple.
Convenient and space saving
The DSmobile DS-940DW is small and compact, ideal where space is limited. The unique “U-path” paper feed means you are not required to have extra space behind the scanner for the document to feed-through. As the document goes in, it glides over the top of the scanner and is returned to you.
Mixed media, consistent results
Designed to scan a wide range of documents including A4 documents, ID cards and receipts, makes the DSmobile DS-940DW a true work companion. The dedicated roller system, ensures your documents are smoothly fed-through, guaranteeing high-quality, digital files are created every time.
Specifications
Basic Specs
Document Size - Single Sheet - Width
50.8 mm to 215.9 mm
Document Size - Single Sheet - Length
86.4 mm to 1,828 mm
Colour / Monochrome
Yes / Yes
2-Sided (Duplex) Scan
Yes
Colour Depth - Input
48-bit colour processing
Colour Depth - Output
24-bit colour processing
Resolution - Optical
Max. 600 dpi × 600 dpi
Resolution - Interpolated
Max. 1,200 dpi × 1,200 dpi
Product Dimensions (Width X Depth X Height)
319 mm × 63.1 mm × 45.4 mm
Weight
0.691 kg
Memory Capacity
512 MB
Warranty
1 Year Carry in Warranty
Connectivity
Connectivity
Super Speed Micro USB 3.0, Wireless LAN IEEE 802.11 b/g/n (Infrastructure Mode), IEEE 802.11 g/n (Wi-Fi Direct)
Network
Wireless Network Security
WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (AES)
Setup Support Utility
WPS
Operation
Power Source
Lithium battery
USB bus-power
Power Consumption - Scanning
USB3.0 mode 3.6W
Wi-Fi mode 4.4W
Power Consumption - Ready
2.2W @Wi-Fi mode
1.5W @PC mode
Power Consumption - Power OFF
0.11W
Temperature Operating
5 to 35℃
Humidity - Operating
20 to 80%
Humidity - Storage
10 to 90%
Compliance
TWAIN Compliant - Windows®
Windows® 7 SP1 / Windows® 8.1 / Windows® 10/ Windows Server® 2012 / Windows Server® 2012 R2 / Windows Server® 2016 / Windows Server®2019
TWAIN Compliant - Macintosh
macOS v10.12.x/10.13.x/10.14.x
