ADS-1700W Scanner
Compact wireless document scanner
- 25ppm/50ipm, 2-sided colour scan speed
- 20 sheets Automatic Document Feeder (ADF)
- Wireless network connectivity
- Dedicated plastic ID card slot
- Zero-touch scanning with auto start scan
- Create up to 20 shortcuts on the easy to use 7.1cm colour touchscreen
Information
Overview
Time-saving shortcuts
Scanning to different locations has just got easier. Reduce the time you spend on repetitive tasks with auto start scan. Documents will automatically be scanned as soon as you insert it into the ADS-1700W. Frequently used scan-to destinations can also be setup as one-touch shortcuts on the touchscreen.
Industry leading software
Easily convert, edit and share documents with Nuance Power PDF. Available as standard on both the ADS-1200 and ADS-1700W, you now have the flexibility to make the changes that you need.
Versatile media handling
The 20 sheet Automatic Document Feeder (ADF) manages paper up to 128gsm with ease. Whilst a dedicated card slot comfortably handles plastic ID cards up to 1.02mm.
High performance
Scanning up to 25 sheets per minute, your documents can be saved quickly to file, email server, USB host, network and direct scan to PC.
Specifications
Basic Specs
Scanning Speed
25ppm/50ipm, (A4) 2-sided colour scan speed
Document Size - Multiple Sheets - Width
51 mm to 215.9 mm
Document Size - Multiple Sheets - Length
70 mm to 863 mm
Document Size - Single Sheet - Width
51 mm to 215.9 mm
Document Size - Single Sheet - Length
70 mm to 863 mm
Colour / Monochrome
Yes/Yes
2-Sided (Duplex) Scan
Yes
Colour Depth - Input
48-bit colour processing
Colour Depth - Output
24-bit colour processing
Resolution - Optical
Max. 600 dpi × 600 dpi
Resolution - Interpolated
Max. 1,200 dpi × 1,200 dpi
Document Scanning Width / Length
Max.216 mm
Product Dimensions (Width X Depth X Height)
300 mm × 103 mm × 83 mm
Weight
1.41 kg
ADF (Automatic Document Feeder)
Up to 20 sheets
Memory Capacity
SDRAM: 512 MB
Warranty
1 Year Carry in Warranty
Connectivity
Connectivity
Super Speed Micro USB 3.0, Wireless LAN IEEE 802.11 b/g/n (Infrastructure Mode), IEEE 802.11 g/n (Wi-Fi Direct), IEEE 802.11 g (Wi-Fi Direct)
Network
Wireless Network Security
WEP 64/128-bit, WPA-PSK (TKIP/AES), WPA2-PSK (AES)
Setup Support Utility
WPS
Display Type
Touchscreen LCD
7.1cm LCD colour touchscreen
Operation
Power Source
AC: 220 - 240 V, 50/60 Hz
Power Consumption - Scanning
Approx. 9W
Power Consumption - Ready
Approx. 4.5W
Power Consumption - Power Saving / Deep Sleep
Approx. 1.5W
Power Consumption - Power OFF
Approx. 0.1W
Temperature Operating
5°C to 35°C
Humidity - Operating
20% to 80%
Humidity - Storage
10% to 90%
Compliance
TWAIN Compliant - Windows®
Windows 7 SP1/8/8.1/10
Server2008 R2 SP1/2012/2012 R2/2016
TWAIN Compliant - Macintosh
MacOS v10.11.6/10.12x/10.13x
WIA Compliant - Windows®
Windows 7 SP1/8/8.1/10
Server2008 R2 SP1/2012/2012 R2/2016
ICA Compliant - Macintosh
MacOS v10.11.6/10.12x/10.13x
